The SCAILX-MIPI-S is a SCAiLX interface board for connecting the Sony® FCB-EV9500M to the SCAILX-SOM-AI board with 4-lane MIPI support and VISCA camera control.
The SCAILX-MIPI-S is a half-size (42x20.25 mm) board that fits directly on the SCAILX-SOM-AI module, connecting to the CSI0-IN MIPI connector. The half-size board will not block access to other board connectors and can be used with the SCAILX-LVDS-2-MIPI board on the CSI1-IN connector or other SCAiLX cameras via SCAILX-FLEX cable.
Disclaimer: While Videology makes reasonable efforts to maintain current CAD models, STEP files available on this website may not reflect the latest product revision. Users must confirm all dimensions and specifications with the Videology Support and Engineering teams before use.
